Cab
Cab
Front Axle
MFWD w/ Suspension
Transmission
Power Shift
Guidance-ready
Yes
Guidance Display
Yes
Rear PTO
540/1000
Rear Tires
Duals
Tire Width
Mid
e23 Transmission 50 km/h (31 mph) with Efficiency Manager
4600 CommandCenter
CommandCenter AutoTrac Activation - 4600 Processor
4600 Processor
Premium CommandView III Cab with Active Seat
Premium Radio Package with XM Radio
Left-hand Reverser Bump-Shift-Type Transmission Controls
John Deere PowerTech 6.8 L (414 cu. in.) 6 Cylinder Tier 4/Stage V Compliant Diesel Engine
223 L/min (59 gpm) Hydraulic Pump
Four Premium Rear Remote SCVs with Electrohydraulic Controls, Premium Couplers and High Pressure Relief Levers
45 mm (1-3/4 in.) 1,000 rpm (20-spline) PTO, 35 mm (1-3/8 in.) 540 rpm (6-spline) / 1,000 rpm (21-spline) PTO
6,894 kg (15,200 lb) capacity 3-Point Hitch (Cat 3/3N) with Quik-Coupler
Category 3 Adjustable Swinging Drawbar for use with a 38 mm (1.50 in.) Pin
110 mm (4.33 in.) diameter by 3010 mm (118.5 in.) length
Cast Wheels with Double Taper Hubs
520/85R46 158B R1W Radial in Dual Wheel Configuration
Firestone Brand Only
1300 Series MFWD with TLS Plus, Driveline Shield, Hydraulic On/Off Differential Lock and Wet Disk Front Brakes
420/85R34 147B R1W Radial
Premium Lighting
Fenders, Pivoting Front - 620 mm (24.4 in.) Wide
Ethernet Switch
Antenna Mount and Wiring for Business Band (2-Way) Radio
Foot Operated Speed Control
Engine Block Heater, 110V
Auxiliary Hydraulic Connections - 1/2 in.
Trailer Brake, Hydraulic
Battery Disconnect Switch
Weight, front support less weights
One Pair 625 kg (1,378 lb) Weights
